GOKU F405 HD 1-2S 12A AIO ELRS V2

Name: GOKU F405 HD 1-2S 12A AIO ELRS V2 - Quadkart
Brand: Flywoo
Price: 8699 INR
Availability: InStock

GOKU F405 HD 1-2S 12A AIO ELRS V2 - Image 2

GOKU F405 HD 1-2S 12A AIO ELRS V2 - Image 3

GOKU F405 HD 1-2S 12A AIO ELRS V2 - Image 4

GOKU F405 HD 1-2S 12A AIO ELRS V2

With the growing popularity of digital transmission, FLYWOO introduces an innovative solution for 1-2S HD Micro Drones.

This full-featured HD AIO solution integrates a Type-C interface, equipped with a high-performance F405 BGA MCU, and offers enoug Uart to meet the meet all you need. The GOKU F405 HD V2 AIO features a built-in 9V 2A BEC module, effectively preventing power cuts in the O3 Air unit due to insufficient voltage.

Additionally, it comes with a serial ELRS 2.4G receiver, an 8MB black box, a barometer, and a current sensor, specifically designed for HD VTX. Its socket-style motor connections and plug-and-play O3 design significantly simpliy the installation and debugging process, achieving a perfect blend of efficiency and convenience.

₹8,699

Price is Inclusive of GST. Enter GST number at checkout.

Options

Clear

Same Day Shipping

Mon-Sat til 2.00PM on Most orders

Provide Warranty

Seller & Manufacturer Warranty

Best Prices

Best Prices in India

Best Customer Support

Industry leading support

Highlights：

Type-C Design: Utilizes Type-C , more convenient and reliable connections.
New Power Supply : Features 9V 2A BEC , effectively preventing power outages in the O3 Air unit due to voltage dropping .
Plug-and-Play O3 Port: Direct plug design for O3 air unit eliminates complex soldering steps
Motor Socket Design: Adopts socket connections for motors to facilitate quick replacements and upgrades.
Multifunctional Design: Integrates a serial ELRS 2.4G receiver, 8MB black box, barometer, and current sensor, reserves 2 full UARTs and 1 standard SBUS port, supporting connections with various devices like GPS, HD VTX, and external receivers.

	GOKU F405 HD 1-2S ELRS AIO V2	GOKU F405 1-2S 12A AIO ELRS
Firmware:	FLYWOOF405S_AIO	FLYWOOF405S_AIO
BEC:	5V 2A/9V 2A	5V 2A
Flash:	8M	8M
LED:	2*WS2812	2*WS2812
Barometer:	DPS310/SPL06	DPS310/SPL06
Gyro:	ICM42688P MPU6000	ICM42688P MPU6000
Motor:	M1-M4 OUTPUT I2C: SCL/SDA	M1-M4 OUTPUT I2C: SCL/SDA
Uarts:	1,2,3,4,5,6	1,2,3,4,5,6
connector：	Type-C	Micro
OSD:	NO	AT7456E
Hole:	25.5*25.5-3mm	25.5*25.5-3mm
Size:	30*30mm	30*30mm
Weight:	4.9g	4.1g
