- MCU: STM32F722RGT6 216MHz
- IMU: MPU6000 (SPI)
- OSD: Betaflight OSD & DJI HD OSD (UART6)
- 6 hardware UARTS (UART1,2,3,4,5,6)
- Barometer: YES
- Buzzer Pad: YES
- 5V 2A & 10V 2A
- Input Voltage: 3-6S Lipo
- Blackbox: 16MB
- Firmware: SKYSTARS F7HDPRO
- Dimensions: 31x30x7.8mm
- Mounting Holes: Standard 20mm/M3 or M2 square to the centre of holes
- Weight: 6g
- For corners have LED Pads that support WS2812 Programmable LED.
- Supports serial receivers (CRSF,SBUS, iBus, Spektrum) and 3.3V Satellite Receiver.
- High-performance / low-noise / high sensitivity IMU. BMI270 with 6-axis gyro and accelerometer
- Plug and connect Port for DJI HD Air Unit Module (connector cables Included)
- Input voltage 10V-26V (3-6S)
