RCINPOWER GTS2306 2306 V2 2500KV 3-5S Motor

RCINPOWER GTS2306 2306 V2 2500KV 3-5S Motor

RCINPOWER GTS V2 2305 2306 series 1800kv 2500kv 2750kv brushless motor are specially designed for fast speed fpv racing drones. If you want powerful motors, choose them, you will not be regreted.

Out of stock


Orders placed before are shipped on same day

Out of stock

Main Features
260 grade radiation resistant high temperature winding
A.I.P Anti-impact Gasket
B.F.P Buffer Filter Ring
High Hardness M3 Tail Screw Fixing Structure
Newly Designed Integrated Rotor
Reinforced TC4-PRO Integrated Spindle

Item Model: GTS2306 V2
KV: 2500KV
Color: Red
Configuration: 12N14P
Stator Diameter: 23mm
Stator Length: 6mm
Shaft Diameter: 4mm(Hollow)
Motor Dimension(Dia. Len): Ф29*30.7mm
Idle current(10)@10V(A): 2.2
No.of cells: 3-5S
Max Continuous power(W)180S: 1100
Internal Resistance: 39mΩ
Max Current(30S): 55A
Max. Effciency Current: (4-8A)>81%
Weight: 31g (3cm Wire)

Package Included:
RCINPOWER GTS V2 2306 2500KV 3-5S Brushless Motor x 1

Weight 35 g
