ToolKitRC M7 AC 200W 15A 2-6S DC Smart Charger

ToolKitRC M7 AC 200W 15A 2-6S DC Smart Charger

The ToolkitRC M7 has been reinvented and is better than ever! The M7 AC is the same size as its predecessor and is 33% more powerful with a max output of 200W and 15A!

In stock

6,499

Orders placed before are shipped on same day

In stock

ToolKitRC M7 AC 200W 15A 2-6S DC Smart Charger

6,499

The ToolkitRC M7 has been reinvented and is better than ever!

This charger is equipped with a full-color IPS LCD screen that is easily navigatable with its smooth roller selector. The M7 AC is the same size as its predecessor and is 33% more powerful with a max output of 200W and 15A! Now including ToolkitRC’s dual sliding connector doors which allow you to switch from XT30 to XT60 in a flash!!

Features

  • Battery Charger
  • Cell Checker
  • Servo Tester
  • PWM, PPM.SBUS Input/output & Receiver tester
  • Viable AMP/volt DC Power supply (Required external DC input
  • Lithium battery cut-off voltage can be set (TVC function)
  • Measure battery voltage, internal resistance, balance
  • Measure PWM / PPM / xBUS signal values, Accuracy 1ms
  • Output PWM / PPM / xBUS standard signal, Accuracy 1ms
  • Customizable 1-28V constant voltage, 1-10A constant current
  • Charge the drone battery, activate and charge.
  • Multi-language optional
  • USB 2.1A@5.0V Output,for Mobile devices

Specifications

  • LCD: IPS  2.0inch
  • LCD: 320*240 Pixel
  • Input voltage: 7.0-28.0V  @MAX 12A
  • Input voltage: AC 100-240V MAX 100W 1.5A
  • Type of battery:
    • Lipo  LiHV  LiFe Lion@1-6
    • NiMh @1-16S   Pb @1-10S
  • Balance current: 400mA @2-6S
  • Charger power:
  • 200W @MAX 15A
  • Discharge power:
    • 200W  @MAX 10A Recycle mode
    • 10W@3A Normal mode
  • USB: 2.1A @5.0V or Upgrade
  • Product size: 112×72*38 mm
  • Product weight: 245g
  • Pack size: 144x73x38mm
  • Pack weight: 380g

Input

  • PWM: 880-2200us @20-400Hz
  • PPM: 880-2200us*8CH @20-50Hz
  • SBUS: 880-2200us*16CH @20-100Hz
  • Voltage: 1.0-5.0V @1-6S
  • Internal resistance: 1-99mR @1-6S
  • ESC: 200W@10A       PWM Output

Output

  • PWM: 500-2500us @20-1000Hz
  • PPM: 880-2200us*8CH @20-50Hz
  • SBUS: 880-2200us*16CH @20-100Hz
  • Power supply: 1.0-28.0V  @1.0-10A  mode:CC+CV
  • OverCurrent Cutoff time: <5ms

Includes

  • 1x ToolKitRC M7 200W 10A 1-6S DC Smart Charger & Diagnostic Tool
Weight 560 g
