SunnySky A2212 Brushless Motor

Stator Diameter 22mm Weight 56g
Stator Thickness 12mm Rotor Diameter 27.5mm
No.of Stator Slots 12 Body Length 40mm
No.of Rotor Poles 14 Max Lipo Cell 3-4S
Motor Kv 980 ESC 20A
No-load current 0.7A/10V Recommended Prop(inch) 9045
Motor Resistance 123mΩ
Max Continuous Current 20A/30s
Max Continuous Power 330W



Prop(inch) Voltage(V) Amps(A) Thrust(gf) Watts(W) Efficiency(g/W) Load temperature in 100% throttle
9450 11.1 0.9 100 10 10.01 112℃
1.9 200 21 9.48
3.2 300 36 8.45
4.6 400 51 7.83
6.2 500 69 7.27
8 600 89 6.76
10.2 720 113 6.36
12.5 0.7 100 9 11.43
1.7 200 21 9.41
2.9 300 36 8.28
4.2 400 53 7.62
5.6 500 70 7.14
7.3 600 91 6.58
9 700 113 6.22
11.9 860 149 5.78
14.8 0.6 100 9 11.26
1.5 200 22 9.01
2.5 300 37 8.11
3.7 400 55 7.3
5 500 74 6.76
6.4 600 95 6.33
8 700 118 5.91
9.7 800 144 5.57
11.6 900 172 5.24
13.5 1000 200 5.01
15 1090 222 4.91
16.5 0.5 100 8 12.12
1.4 200 23 8.66
2.3 300 38 7.91
3.5 400 58 6.93
4.6 500 76 6.59
6 600 99 6.06
7.5 700 124 5.66
8.9 800 147 5.45
10.5 900 173 5.19
12.5 1000 206 4.85
14.3 1100 236 4.66
16.6 1220 274 4.45
Weight N/A
KV

1400KV, 980KV
