Features:

• Stable output power
• 4 power levels up to 3000 mW
• 56 channels (including Raceband)
• Fast frequency lock, no interference when starting for other pilots
• Built-in output power self-test function
• VTX telemetry with IRC Tramp protocol
• Dimensions: 3.8 cm x 3.8 cm x 1.3 cm

Tips: The VTX is set to 25mW by default! Power levels above 25mW require a HAM license or must be approved by local authorities! Make sure you are using legal frequencies and use the prepared VTX tables for Betaflight according to your region.

Characteristics:

• Input voltage: 9V~35V
• Interface: MMCX
• Power levels: PIT/25mW/400mW/1000mW/3000mW
• Channels: 56 (including Raceband)
• Mounting template: 20×20 mm/Φ2
• Weight: 31.4 g
• VTX Telemetry: IRC Tramp
• VTX table values ​​for IRC Tramp: 25mW/400mW/1000mW/3000mW

Equipment:

• 1x Skystars 4.9-5.8G 3W video transmitter
