A custom-built Cinewhoop FPV Drone kit with the best combination of parts to get you started on the FPV journey. Built by experts at Quadkart, curated for your Cinematic stunning footage. Kindly get in touch with us if you have any doubts about this product before placing an order.

Features

• Upgraded with half EVA Duct protectors, less noise, and more durability.
• Duct design, firm structure, and lightweight.
• Works well with HD video transmitters and GoPro cameras.

Specifications

Veyron30CR Cinewhoop Frame
Model:3 inches Frame
Wheelbase:140mm
Size:215*190mm

DYS F7 Mini FC
Gyro:MPU6000
Input voltage:3-6S Lipo

Zeus 28A BL_S ESC
Input voltage:3-6S
Continuous current:28A
Peak current:35A (10 seconds)

Zeus nano 350mW VTX
Output Power:PIT/25/100/200/350mW
Input Voltage:DC 5V
Antenna:IPEX

Foxeer Predator 5 Micro
Input Power:DC 5-40V
Dimensions:19mm*19mm*20mm

AEOLUS 2004 3000KV motor
Motor:KV3000
Input voltage:3-4S
Recommended blade:3 inches

AEOLUS 2004 2600KV motor
Motor:KV2600
Input voltage:6S
Recommended blade:3 inches

Gemfan 3 inch 5-blades propeller
Quantity:4 CW & 4 CCW

FrSky Qx7 ACCESS Radio
Frequency: 2.4Ghz
Input voltage: 2-3S

Eachine EV800D Goggles
Screen Size: 5.0Inch
Resolution: 800*480

ToolkitRC M6 V2 Charger
Modes: Lipo/Liion,Ni-Cd/Pb
Input voltage:7-28v
Charge Power:150W/ Upto 10A

CNHL 1100Mah 6S 100C Blackseries Lipo
Capacity:1100 Mah
C rating:100C

ToolkitRC ADP100 100W Power Supply
Output Current:5A

Package includes:
1x DYS F7 mini flight controller
1x Zeus 28A BL_S ESC
4x AEOLUS 2004 3000KV motor/AEOLUS 2004 2600KV motor
1x Veyron30CR Cinewhoop Frame
1x Zeus 350mW nano VTX
1x Foxeer Predator 5 Micro FPV Cam
8x Gemfan 5-blades propellers
1x SMA Hammer Antenna (RHCP)
1x Receiver (R-XSR)
1x Qx7 ACCESS Radio
1x Eachine EV800D Goggles
1x ToolkitRC M6 V2 Radio
1x ADP100 5A Power Supply
1x CNHL 1100Mah 6S 100C Lipo
