GEPRC-Mark4-10 Frame

New

GEPRC-Mark4-10 Frame

GEP-Mark-10 is a frame designed to manage heavy-loads flights. It can carries a maximum payload of 3kg when applied with a 3214 or 3115 900KV motor. The light-design structure enables immediate response even when flying with extra weight.

The FC fixing hole size is 30.5×30.5mm(M3), Camera lens fixing hole size is19x19mm(M2), Motor fixing hole size is 19x19mm(M3). Reserved enough space for VTX installation at the end of the frame, and the extended dimension frame can mount up to LiPo 6S 8000mah battery.

Out of stock

₹5,499

Out of stock

Add to wishlist

Same Day Shipping

Mon-Sat til 2.00PM on Most orders

Provide Warranty

Seller & Manufacturer Warranty

Best Prices

Best Prices in India

Best Customer Support

Industry leading support

Feature

The extended dimension frame leaves enough space to accommodate the large-capacity battery and increases flight time.
Equipped with the vertical-shaped reinforce arm to enhance stabilization and reduce the impact of unsteady on the gyroscope.
The 3.7mm thickness arm structure ensures the rigidity of the frame.
Adopting the 30 mm Aluminum standoff leaves sufficient stacking space.
It supports three types of fixing hole size of VTX : 30.5×30.5mm(M3)、25.5×25.5mm(M2)、20x20mm(M2).

Specification

Item: GEP-Mark4-10 Frame
Dimension: 376mmx303mm
Motor to motor：429mm
Top plate: 2mm
Base plate: 3mm
Side plate: 2.5mm
Arm plate: 7mm
Midplate：3mm
Arm bar：3mm
Camera fixing hole size: 19x19mm(M2)
Motor fixing hole size: 19x19mm（M3）
FC fixing hole size: 30.5×30.5mm（M3
VTX fixing hole size: 30.5×30.5mm（M3）/25.5×25.5mm（M2）/20x20mm（M2）
Weight: 270.0g

Includes

1x GEP-Mark4-10 Frame

1x M20*300mm battery strap

1x Battery Silicone anti-slip Pad

4x EVA landing Pads

Weight	300 g
